特点   Features
◎  热风多次穿过物料层与物料逆向流动，使热交换充分，热效率高。
◎  结构紧凑，占地面积小。
◎  物料在床内停留时间可调节，操作方便。
◎  物料沿螺旋床自下而上作圆周运动的同时，自身也产生跳跃，从而增加了物料与热风的接触，增强了干燥效果。
◎  连续的进出料适合于流水线，并且易达到GMP规范，可代替传统的箱式干燥。
◎  对物料的表面及形状基本没有损伤，不仅保证了丸剂的圆度，而且大大的降低了丸剂的破碎率。

◎  Because the hot air passes through the layer of raw material several tiers and acts counter motion towards the raw material, the heat exchanger is fully preferment and thermal efficiency is high.
◎  The structure is compact and it occupies small area.
◎  The stay time of raw material in thehelix bed can be adjusted and the operation is very convenient.
◎  The raw material acts the motion if circle at helix bed from up to low, at the same the equipment can jump itself, so the contact surface between hot air and raw material is increased too and the dry effects is strengthened.
◎  The equipment is suitable for continuous operation because of continuous feeding and discharging raw material Meanwhile it is easy to meet the requirements of GMP.
◎  It does not damage the surface and shape of raw material basically. It can not only maintain the roundness of pill but also decrease the rate of pills.
----------------------------------------------------------------------------------------------------------------
应用   Application
        LZG螺旋振动干燥机主要适用于中药丸剂的干燥，也可适用于化工、制药、食品、塑料、建材、饲料等行业的颗粒状、短条状、球状物料的干燥。
LZG helix vibration drier is mainly used for drying pill of Chinese traditional medicine. It can also be suitable for drying granule, short strip and ball raw material of chemical industry, pharmaceutical industry, foodstuff industry, construction material industry, feed industry and so on.
----------------------------------------------------------------------------------------------------------------
结构示意图   Schematic of structure

----------------------------------------------------------------------------------------------------------------
技术参数   Technical parameters
型号 spec                  单位 unit  LZG-1.0  LZG-1.2  LZG-1.4  LZG-1.6  LZG-1.8
直径 diameter              mm          1000     1200      1400       1600     1800
振动电机功率  power       kw        2×0.8     2×0.75   2×1.5    2×1.5      2×2.2
外形尺寸over all dimensions   m       1.2×1.2×2.7  1.4×1.4×2.7   1.6×1.6×3.3   1.8×1.8×3.3   2.0×2.0×3.3
重量  weight                 kg        1400       1680       2800     3100       3800
生产能力production capacity    kg/h     80-120   120-200   200-280  280-350  350-450
进风温度temperature of air intel  ℃      60-200     60-200    60-200    60-200   60-200
风量   air amount         m3/h      1487        2380       3721      4462     5930
风机功率  power of fan   kw          4.1           7          7.7        14          24
