1.电阻测量范围Resistance measuring range

104Ω～1×1013Ω

104Ω ～1012Ω

2.电阻率测量范围Resistivity measuring

104～ 2.0×1013 Ω-cm

104 ～ 2.0×1012 Ω-cm

3.测试电压Test voltage

0-1000V

0-500V

4.基本准确度accuracy

1%

5. 显示display

液晶显示:电阻率、温度、电流电压、可输入测试样品数据LCD: resistivity. temperature. current voltage. input test sample data

6. 使用环境environment

温度：0℃～40℃，相对湿度<80%

7. 电源Power supply

AC 220V，50HZ， 5W

8.测量模式Measuring mode

配置232和USB通讯接口，液晶显示测试或者PC软件下测试Configure 232 and USB communication interface. LCD or PC software test

9. 选购治具choose by fixture

1.FT-05A固体三环电极；2.FT-04A液体极；

3.FT-03A简易粉末和膏体测量装置；

1.FT-05A Solid three-ring electrode.

2.FT-04A Liquid electrode.

3.FT-03A powder and paste simple measuring device.

10.PC软件（选购）

PC software (optional)

PC测试软件USB通讯接口，软件界面同步显示、分析、保存和打印数据！温度与电阻、电阻率的关系曲线；时间与电阻率、电阻的关系曲线.

PC test software USB communication interface. Synchronous display of software interface. analyze. save and print data. Temperature with resistance and resistivity curves. Time with resistivity and resistance curves.

11.尺寸dimensions

L 340mm* W 320mm* H 120mm

L 330mm* W 220mm* H 110mm
