工作原理：Working principle

       管链输送机又称管式拖链输送机，工作时，装有圆盘刮板的链条在封闭的管路中运动，依靠刮板推动物料沿管路向前输送，是一种节能、高效的连续输送设备。

      Tube Chain conveyors is a new type of continous mechanical conveyor,it is suitable for transportation of bulk solid material.Bulk solid material is conveyed in the tube by disks fixed on the chain in a definite distance.Compared with traditional mechanical conveyors such as screw conveyors,TCC with advantage of lower power consumption,high efficiency,three dimension orientation ect.

管链输送系统应用领域：Application fields of tube chain conveying system

塑料工业：PVC、PP、PE粉料，ABS、PC、PP、PE颗粒。

Plastic Industry：PVC、PP、PE Powder，ABS、PC、PP、PE Granulate.

化学工业：染料、颜料、涂料、炭黑、钛色素、氧化粉、陶粉、重质碳酸钙、细颗粒碳酸钙、皂土、分子筛、瓷土、硅粉、活性炭等。

Industry of Chemicals：Dye,paints,coating,carbon black,titanium pigment,ferric oxide,ceramics powder,coarse whiting,fine particale calcium carbonate,bentonite,molecular sieve,kaolin,silica flower,active carbon and etc.

矿业：尿素、氯化铵、碳酸氢铵、苏打粉、固态杀虫剂、钨粉、鱼油、铜矿粉、煤粉、块状磷酸钙、矾土等。

Mineral Industry：Urea,ammonium chloride,ammonium bicarbonate,soda powder,soild pesticide,tungsten power,fish oil,copper fine ore powder,coal powder,rock phosphate,alumina powder and etc.

建筑材料：水泥、粘土、黄沙、石英砂、粘土粉、硅、石灰石粉、白云石粉、木屑、玻璃丝、二氧化硅、画粉等。

Building Material：Cement,clay,yellow sand,quartz sand,clay powder,silica,limestone flour,dolomite fines,Wood chips,fiberglass,silicon dioxide,French chalk and etc.

食品工业：面粉、淀粉、谷类、奶粉、食物添加剂等。

Foodstuff Industry：Flour,starch,grain,milk powder,food additive and etc.

性能特点：Features

结构紧凑，占用空间小，可以三维改变输送方向，不受地形、角度与高度的影响；

Compact size,small space required,could change conveying at horizontal,vretical and inclined orientation.

输送过程在紧密的管路中进行，物料无污染，无粉尘飞扬；

Dust,gas and pressure-tightness is easy to realize,Therefore no product contamination and dust free operation is psssible.

输送过程平滑，物料间基本无内部运动，破损少，保证物料品质，适合磨蚀性物料；

Smooth moving,lower internal fraction of particles,lower damage to material and suitable for abrasive material.

不会产生系统堵塞，适合输送多种形态的物料；

Notube blocking happens,large range material are suitable.对混合物料的输送，不会产生物料分层现象；

No segregation happens for mixed material.

输送能力大，能耗低，大大降低设备运行成本；

High capacity and lower power consumption makes a lower operation cost.

所有运动部件全部在密闭的空间内进行，安全、可靠；

All moving parts working in tube,high safety and high reliability.

可实现远距离输送；

Easily for long distance transportation.

可随意布置多个进、出料口，满足工艺要求；

Multiple material inlet and outlet is possible to meet different process.

易于实现集中控制，提高自动化程度；

Easy to be integrated to an industrial plant for automatic working.

使用条件：Working condition

压力 Pressure:1Mpa Absolute     温度 Temperature:-20℃ to 200℃

材料：Material

管道Tube、机壳Housing、链条Chain、链轮Sorocket:SS304，链板Disk:尼龙 Nylon、

其他(no material contact):碳钢Catbon steel patinted
